Room.x3d (X3dToXhtml listing)

ecmascript: function set_open() { keyValue_changed[0][0] = 0; keyValue_changed[0][1] = 1; keyValue_changed[0][2] = 0; keyValue_changed[1][0] = 0; keyValue_changed[1][1] = 1; keyValue_changed[1][2] = 0; keyValue_changed[1][3] = -0.754; keyValue_changed[2][0] = 0; keyValue_changed[2][1] = 1; keyValue_changed[2][2] = 0; if(open == false) { keyValue_changed[0][3] = 0; keyValue_changed[2][3] = -1.57; open = true; } else { if(open == true) { keyValue_changed[0][3] = -1.57; keyValue_changed[2][3] = 0; open = false; } } }

Event Graph ROUTE Table entries with 6 ROUTE connections total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.

touch_door TouchSensor touchTime SFTime	→ ROUTE event to (1)	clock TimeSensor startTime SFTime	then	clock TimeSensor fraction_changed SFFloat	→ ROUTE event to (2)	open_door OrientationInterpolator set_fraction SFFloat	then	open_door OrientationInterpolator value_changed SFRotation	→ ROUTE event to (3)	transform_door Transform set_rotation SFRotation
touch_door TouchSensor touchTime SFTime	→ ROUTE event to (1)	open_door_js Script set_open SFTime	then	open_door_js Script keyValue_changed MFRotation	→ ROUTE event to (2)	open_door OrientationInterpolator set_keyValue MFRotation	then	open_door OrientationInterpolator value_changed SFRotation	→ ROUTE event to (3)	transform_door Transform set_rotation SFRotation
touch_door TouchSensor touchTime SFTime	→ ROUTE event to (1)	grinding_door AudioClip startTime SFTime

ProtoInstance
Chair

No ROUTE connection found for output events from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declarations with
direct access to other nodes, and thus has potential to produce run-time animation.

ProtoInstance
Desk

ProtoInstance
WallLamp

Anchor

description='link to NPS web page'
User-interaction hint for this node.

Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets. Have fun with X3D! 😀

1	`<?xml version="1.0" encoding="UTF-8"?>`
2	`<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">`
3	<X3D profile='Immersive' version='3.0' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
4	<head>
5	<meta name='title' content='Room.x3d'/>
6	<meta name='description' content='A simple room containing protoype instances for chair, desk lamp, wall clock, etc.'/>
7	<meta name='creator' content='Frederic Roussille'/>
8	<meta name='created' content='1 April 2001'/>
9	<meta name='modified' content='20 October 2019'/>
10	<meta name='identifier' content='https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/Room.x3d'/>
11	<meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
12	<meta name='license' content='../license.html'/>
13	</head>

14	<Scene>
15	<!-- externprodeclare : chair -->
16	<WorldInfo title='Room.x3d'/>
17	<ExternProtoDeclare name='Chair' url=' "Chair.x3d#Chair" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/Chair.x3d#Chair" "Chair.wrl#Chair" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/Chair.wrl#Chair" '>
18	<field name='diffuseColor' type='SFColor' accessType='inputOutput'/>
19	</ExternProtoDeclare>
20	<ExternProtoDeclare name='Desk' url=' "Desk.x3d#Desk" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/Desk.x3d#Desk" "Desk.wrl#Desk" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/Desk.wrl#Desk" '>
21	<field name='diffuseColor' type='SFColor' accessType='inputOutput'/>
22	</ExternProtoDeclare>
23	<ExternProtoDeclare name='WallLamp' url=' "WallLamp.x3d#WallLamp" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/WallLamp.x3d#WallLamp" "WallLamp.wrl#WallLamp" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/WallLamp.wrl#WallLamp" '>
24	<field name='lampColor' type='SFColor' accessType='inputOutput'/>
25	<field name='lightColor' type='SFColor' accessType='inputOutput'/>
26	<field name='lightIntensity' type='SFFloat' accessType='inputOutput'/>
27	<field name='lightAttenuation' type='SFVec3f' accessType='inputOutput'/>
28	<field name='radius' type='SFFloat' accessType='inputOutput'/>
29	<field name='lightLocation' type='SFVec3f' accessType='inputOutput'/>
30	</ExternProtoDeclare>
31	<NavigationInfo headlight='false'/>
32	<Viewpoint description='entry' orientation='1 0 0 -0.2' position='16 23 75'/>
33	<Transform scale='0.4 0.4 0.6'>
34	<Group>
35	<!-- floor -->
36	<!-- Shape wall is a DEF node that has 3 USE nodes: USE_1, USE_2, USE_3 --> <Shape DEF='wall'>
37	<ElevationGrid solid='false' xDimension='9' xSpacing='10' zDimension='9' zSpacing='10' height='0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0'/>
38	<!-- Appearance wallpaper is a DEF node that has 1 USE node: USE_1 --> <Appearance DEF='wallpaper'>
39	<ImageTexture url=' "WallPaper.jpg " "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/WallPaper.jpg " '/>
40	<TextureTransform scale='2 2'/>
41	<Material/>
42	</Appearance>
43	</Shape>
44	<!-- left wall -->
45	<Transform rotation='0 0 1 1.57'>
46	<Shape USE='wall'/>
47	</Transform>
48	<!-- right wall -->
49	<Transform rotation='0 0 1 1.57' translation='80 0 0'>
50	<Shape USE='wall'/>
51	</Transform>
52	<!-- top -->
53	<Transform translation='0 80 0'>
54	<Shape USE='wall'/>
55	</Transform>
56	<!-- front wall -->
57	<Transform rotation='1 0 0 1.57'>
58	<Shape>
59	<Appearance USE='wallpaper'/>
60	<IndexedFaceSet solid='false' coordIndex='0 1 2 7 -1 2 3 6 7 -1 4 5 6 3 -1'>
61	<Coordinate point='0 0 0 25 0 0 25 0 -45 55 0 -45 55 0 0 80 0 0 80 0 -80 0 0 -80'/>
62	</IndexedFaceSet>
63	</Shape>
64	</Transform>
65	<!-- door with its interpalotors and sensors -->
66	<!-- ROUTE information for transform_door node: [from open_door.value_changed to set_rotation ] --> <Transform DEF='transform_door' center='25 0 0'>
67	<Transform translation='40 22.5 0'>
68	<Shape>
69	<Appearance>
70	<ImageTexture url=' "Door.jpg " "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/Door.jpg " '/>
71	</Appearance>
72	<Box size='30 44.5 2'/>
73	</Shape>
74	<!-- ROUTE information for touch_door node: [from touchTime to clock.startTime ] [from touchTime to open_door_js.set_open ] [from touchTime to grinding_door.startTime ] --> <TouchSensor DEF='touch_door' description='touch door to open/close'/>
75	</Transform>
76	<!-- ROUTE information for open_door_js node: [from touch_door.touchTime to set_open ] [from keyValue_changed to open_door.set_keyValue ] --> <Script DEF='open_door_js'>
77	<field name='set_open' type='SFTime' accessType='inputOnly'/>
78	<field name='keyValue_changed' type='MFRotation' accessType='outputOnly'/>
79	<field name='open' type='SFBool' value='false' accessType='initializeOnly'/>
	`<![CDATA[` ecmascript: function set_open() { keyValue_changed[0][0] = 0; keyValue_changed[0][1] = 1; keyValue_changed[0][2] = 0; keyValue_changed[1][0] = 0; keyValue_changed[1][1] = 1; keyValue_changed[1][2] = 0; keyValue_changed[1][3] = -0.754; keyValue_changed[2][0] = 0; keyValue_changed[2][1] = 1; keyValue_changed[2][2] = 0; if(open == false) { keyValue_changed[0][3] = 0; keyValue_changed[2][3] = -1.57; open = true; } else { if(open == true) { keyValue_changed[0][3] = -1.57; keyValue_changed[2][3] = 0; open = false; } } } `]]>`
81	</Script>
82	<!-- ROUTE information for clock node: [from touch_door.touchTime to startTime ] [from fraction_changed to open_door.set_fraction ] --> <TimeSensor DEF='clock' cycleInterval='4.5'/>
83	<!-- ROUTE information for open_door node: [from open_door_js.keyValue_changed to set_keyValue ] [from clock.fraction_changed to set_fraction ] [from value_changed to transform_door.set_rotation ] --> <OrientationInterpolator DEF='open_door' key='0 0.5 1' keyValue='0 1 0 0 0 1 0 0 0 1 0 0'/>
84	</Transform>
85	<!-- link to nps site -->
86	<Anchor description='link to NPS web page' url=' "https://www.nps.edu" '>
87	<Transform translation='40 22.5 -20'>
88	<Shape>
89	<Appearance>
90	<Material diffuseColor='0 0 0'/>
91	</Appearance>
92	<Box size='30 44.5 1'/>
93	</Shape>
94	</Transform>
95	</Anchor>
96	</Group>
97	<!-- Door sound -->
98	<Sound direction='0 1 1' location='40 0 0' maxBack='150' maxFront='150'>
99	<!-- ROUTE information for grinding_door node: [from touch_door.touchTime to startTime ] --> <AudioClip DEF='grinding_door' description='GrindingDoor' url=' "GrindingDoor.wav" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/GrindingDoor.wav" '/>
100	</Sound>
101	</Transform>
102	<!-- chair inserted -->
103	<Transform scale='1.5 1.5 1.5' translation='10 5.3 35'>
104	<ProtoInstance name='Chair'>
105	<fieldValue name='diffuseColor' value='0 0.3 0.7'/>
106	</ProtoInstance>
107	</Transform>
108	<!-- desk inserted -->
109	<Transform rotation='0 1 0 -0.754' scale='0.8 0.8 0.7' translation='18 8.1 28'>
110	<ProtoInstance name='Desk'/>
111	</Transform>
112	<!-- left wall_lamp -->
113	<Transform rotation='0 1 0 1.57' scale='2 2 2' translation='0.05 23 20'>
114	<ProtoInstance name='WallLamp'>
115	<fieldValue name='lampColor' value='0 0 1'/>
116	<fieldValue name='lightColor' value='1 1 1'/>
117	<fieldValue name='lightIntensity' value='0.8'/>
118	<fieldValue name='lightAttenuation' value='0 0 0'/>
119	<fieldValue name='radius' value='100'/>
120	<fieldValue name='lightLocation' value='0 0 5'/>
121	</ProtoInstance>
122	</Transform>
123	<!-- right wall_lamp -->
124	<Transform rotation='0 1 0 -1.57' scale='2 2 2' translation='31.99 23 20'>
125	<ProtoInstance name='WallLamp'>
126	<fieldValue name='lampColor' value='0 0 1'/>
127	<fieldValue name='lightColor' value='1 1 1'/>
128	<fieldValue name='lightIntensity' value='0.8'/>
129	<fieldValue name='lightAttenuation' value='0 0 0'/>
130	<fieldValue name='radius' value='100'/>
131	<fieldValue name='lightLocation' value='0 0 -5'/>
132	</ProtoInstance>
133	</Transform>
134	<!-- clock inserted on the wall -->
135	<Transform translation='16 22.5 0'>
136	<Inline url=' "WallClock.x3d" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/WallClock.x3d" "WallClock.wrl" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/WallClock.wrl" '/>
137	</Transform>
138	<!-- desk lamp inserted in the scene -->
139	<Transform scale='15 15 15' translation='16 8.6 25'>
140	<Inline url=' "DeskLamp.x3d" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/DeskLamp.x3d" "DeskLamp.wrl" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/DeskLamp.wrl" '/>
141	</Transform>
142	<!-- routes for the door -->
143	< ROUTE fromNode='touch_door' fromField='touchTime' toNode='clock' toField='startTime'/>
144	< ROUTE fromNode='touch_door' fromField='touchTime' toNode='open_door_js' toField='set_open'/>
145	< ROUTE fromNode='touch_door' fromField='touchTime' toNode='grinding_door' toField='startTime'/>
146	< ROUTE fromNode='open_door_js' fromField='keyValue_changed' toNode='open_door' toField='set_keyValue'/>
147	< ROUTE fromNode='clock' fromField='fraction_changed' toNode='open_door' toField='set_fraction'/>
148	< ROUTE fromNode='open_door' fromField='value_changed' toNode='transform_door' toField='set_rotation'/>
149	</Scene>
150	</X3D>

X3D Model Documentation: Room.x3d
